Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| MITSUBISHI | M2T84071 |
Ref No
| MITSUBISHI | MD312857 |
| LESTER | 32367 |
| LUCAS | LRS01367 |
Adapted models
| MITSUBISHI | L200 2.5D 4D56 1994-98 |
| MITSUBISHI | L300 2.5D 4D56 1994-98 |
Components
Mounting type
| Mount Hole Dia | M10,M10 |
| Flange Dia | 77mm |
| Mount Holes Cnt to Cnt | 106mm |
| Pinion Dia | 32mm |
| Out of Mesh Clearance | 2mm |
| Overall Length | 226mm |
| HSG Length | 187.5mm |
| Rest Position B | 141mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 4.7Kg |
