Specification
| Volt | 12V |
| Power | 3.0KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| MAGNETI MARELLI | 63193001 |
Ref No
| JCB | 71440231 |
| CATERPILLAR | 225-3149 |
| PERKINS | 2873K405 |
| LESTER | 18940 |
| LUCAS | LRS02425 |
Adapted models
| JCB | 526S 4.4D 1104C-44R 1997- |
| KIOTI | DK65 2.7D 90327T 2002-07 |
| PERKINS Engine | 1103D-33 2004- |
Components
Mounting type
| Mount Hole Dia | 11.5mm, 11.5mm, 11.5mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 90*90*127mm |
| Pinion Dia | 40mm |
| Out of Mesh Clearance | 30mm |
| Overall Length | 295mm |
| HSG Length | 225mm |
| Rest Position B | 150mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG |
