Specification
| Volt | 12V |
| Power | KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| FORD | E3TF-11001-AA |
Ref No
| FORD | E4TF-11001-AA |
| LESTER | 3185 |
| LUCAS | LRS01407 |
Adapted models
| FORD | Bronco,Pick Up w/AT 4.9/5.0L |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 105mm |
| Mount Holes Cnt to Cnt | 134mm |
| Pinion Dia | 25mm |
| Out of Mesh Clearance | 6mm |
| Overall Length | 243mm |
| HSG Length | |
| Rest Position B | 194.5mm |
| S terminal size | |
| B+ terminal size | M6 |
| WEIGHT KG |
