Specification
| Volt | 12V |
| Power | 1.6KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| MITSUBA | SM612-06 |
Ref No
| HONDA | 31200-PPA-A02 |
| LESTER | 17844 |
| LUCAS | LRS03997 |
Adapted models
| HONDA | CR-V 2.4L K24A1 2002-06 |
Components
Mounting type
| Mount Hole Dia | 10.5mm, 13mm |
| Flange Dia | 75mm |
| Mount Holes Cnt to Cnt | 115.5mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 33.5mm |
| Overall Length | 225.5mm |
| HSG Length | 161.5mm |
| Rest Position B | N/A |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
