Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| DENSO | 028000-4990 |
Ref No
| BOBCAT | 6653920 |
| KUBOTA | 15401-63010 |
| NEW HOLLAND | 503470 |
| LESTER | 16650 |
| LUCAS | LRS01129 |
Adapted models
| KUBOTA ENGINE | D1402 1979- |
| KUBOTA ENGINE | V1502 1979- |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 82.2mm |
| Mount Holes Cnt to Cnt | 104.8mm |
| Pinion Dia | 33.8mm |
| Out of Mesh Clearance | 24.5mm |
| Overall Length | 189mm |
| HSG Length | 151.5mm |
| Rest Position B | 101mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.6Kg |
