Specification
| Volt | 12V |
| Power | 2.5KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001362073 |
Ref No
| FIAT | 4448694 |
| LESTER | 30828 |
| LUCAS | LRS00828 |
Adapted models
| ALFA ROMEO | AR6 2.5D 814467 1986-89 |
| FIAT | 131 2.0D Panorama 814465 1978-84 |
| FIAT | Ducato 2.4D 814461 1982-85 |
Components
Mounting type
| Mount Hole Dia | 12.2mm, 12.2mm, 12.2mm |
| Flange Dia | 110mm |
| Mount Holes Cnt to Cnt | 146mm |
| Pinion Dia | 34.5mm |
| Out of Mesh Clearance | 25.2mm |
| Overall Length | 293mm |
| HSG Length | 221.5mm |
| Rest Position B | 170.5mm |
| S terminal size | |
| B+ terminal size | M10 |
| WEIGHT KG | 12.6Kg |
