Specification
| Volt | 12V |
| Power | 1.8KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| DENSO | 428000-7881 |
Ref No
| VW | 03L911024A |
| LUCAS | LRS02575 |
Adapted models
| AUDI | A4 B8 2.0D CJCA 2007-15 |
| AUDI | A5 2.0D CAHA(8T3) 2008-12 |
| AUDI | Q5 2.0D CAGA/CJCA (8RB) 2009-13 |
Components
Mounting type
| Mount Hole Dia | 12mm, M12 |
| Flange Dia | 65.8mm |
| Mount Holes Cnt to Cnt | 135mm |
| Pinion Dia | 33.1mm |
| Out of Mesh Clearance | 22mm |
| Overall Length | 229.5mm |
| HSG Length | 169mm |
| Rest Position B | 155.5mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.3Kg |
