Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| HITACHI | S114-429A |
Ref No
| ISUZU | 8941333380 |
| LESTER | 17079 |
| LUCAS | LRS01553 |
Adapted models
| ISUZU | Engine 3KC1 1989-96 |
Components
Mounting type
| Mount Hole Dia | 11.8mm, 11.8mm |
| Flange Dia | 79.7mm |
| Mount Holes Cnt to Cnt | 110mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 20mm |
| Overall Length | 199mm |
| HSG Length | 175mm |
| Rest Position B | 138mm |
| S terminal size | M5 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.7Kg |
