Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 20T |
| Rotation | CW |
OE NO
| HITACHI | S114-438B |
Ref No
| YANMAR | 105100-77010 |
Adapted models
| YANMAR | Engine 3TNV82-QTB1 |
| YANMAR | Engine 3TNV88F |
Components
Mounting type
| Mount Hole Dia | 9mm, M12, M12 |
| Flange Dia | 80mm |
| Mount Holes Cnt to Cnt | 107.5mm |
| Pinion Dia | 56mm |
| Out of Mesh Clearance | 18.8mm |
| Overall Length | 216mm |
| HSG Length | 197mm |
| Rest Position B | 172.5mm |
| S terminal size | M4 |
| B+ terminal size | M8 |
| WEIGHT KG | 4.7Kg |
