Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| VALEO | TS22E20 |
Ref No
| GM | 55564374 |
| LESTER | 30555 |
| LUCAS | LRS02509 |
Adapted models
| CHEVROLET | Trailblazer 2.8D LWH 2012- |
Components
Mounting type
| Mount Hole Dia | 10.5mm, 10.5mm |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 122.5mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 20.5mm |
| Overall Length | 216mm |
| HSG Length | 157mm |
| Rest Position B | 126mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.6Kg |
