Starter for NISSAN TERRANO II,RENAULT MASCOTT 3.0 Diesel 2003-10
109-048
12V 2.5KW 9T CW
Specification
| Volt | 12V |
| Power | 2.5KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| HITACHI | S13-527 |
Ref No
| NISSAN | 23300-2W200 |
| LESTER | 33182 |
| LUCAS | LRS02182 |
Adapted models
| NISSAN | TeRano 3.0D ZD30(R20) 2002-06 |
| RENAULT | Master T35 3.0D ZD3600 2005-10 |
Components
Mounting type
| Mount Hole Dia | 11.5mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 119.5mm |
| Pinion Dia | 35mm |
| Out of Mesh Clearance | 10.5mm |
| Overall Length | 213mm |
| HSG Length | 200mm |
| Rest Position B | 174.5mm |
| S terminal size | M5 |
| B+ terminal size | M8 |
| WEIGHT KG |
