Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| HITACHI | S114-815 |
Ref No
| ISUZU | 5864002200 |
| YANMAR | 129698-77010 |
| LESTER | 18219 |
| LUCAS | LRS01531 |
Adapted models
| YANMAR | 3JH3-BE |
| YANMAR | 4JH3-E |
Components
Mounting type
| Mount Hole Dia | 13mm, 13mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 120mm |
| Pinion Dia | 33.2mm |
| Out of Mesh Clearance | 20mm |
| Overall Length | 192mm |
| HSG Length | 137.5mm |
| Rest Position B | 111mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 2.9Kg |
