Specification
| Volt | 12V |
| Power | 1.5KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| DELCO | 10455301 |
Ref No
| LESTER | 3510M |
| LUCAS | LRS01284 |
Adapted models
| CHEVROLET | Astro 4.3L LB4 1984-94 |
| CHEVROLET | G10 Chevy L05 1986-93 |
Components
Mounting type
| Mount Hole Dia | 11.5mm, 11.5mm |
| Flange Dia | 82.5mm |
| Mount Holes Cnt to Cnt | 83mm |
| Pinion Dia | 25mm |
| Out of Mesh Clearance | 6mm |
| Overall Length | 293mm |
| HSG Length | 235mm |
| Rest Position B | 196.5mm |
| S terminal size | M4 |
| B+ terminal size | M10 |
| WEIGHT KG |
