Specification
| Volt | 12V |
| Amp | 75A |
| Pulley | 4PV |
OE NO
| MITSUBISHI | A5TB1291ZE |
Ref No
| SUZUKI | 31400-84E01 |
| HC PARTS | JA1612IR |
| LESTER | 23954 |
| LUCAS | LRA02954 |
Adapted models
| SUZUKI | Swift 1.3L M13A 2005-08 |
| SUZUKI | Wagon 1.3L M13A 2003-12 |
Components
Mounting type
| Adj Hole Dia | M8 |
| Piv Hole Dia | 10.5mm |
| Adjuster -Pivot | 164mm |
| Belt limit distance P/A | 54.5mm |
| Inside Ft - Ft/ Pivot Lug Length | 58mm |
| Pulley Dia | 55mm |
| Pulley Type | 4PV |
| B+ terminal dia | M6 |
| D+ terminal diamete | |
| Weight | 4.6Kg |
