Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 12T |
| Rotation | CW |
OE NO
| VALEO | TS2234 |
Ref No
| FORD | BK3T-11000-DB |
| LESTER | 30581 |
| LUCAS | LRS03962 |
Adapted models
| FORD | Tourneo Custom 2.2D CVFF 2012-15 |
| FORD | Transit 2.2D CYFA 2011-14 |
Components
Mounting type
| Mount Hole Dia | 10.5mm, 10.5mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 89mm |
| Pinion Dia | 37mm |
| Out of Mesh Clearance | 20mm |
| Overall Length | 233.5mm |
| HSG Length | 153mm |
| Rest Position B | 126mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.8Kg |
