Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| VALEO | ESW1014 |
Ref No
| DACIA | 23300-3847R |
| MERCEDES BENZ | A4539067500 |
| LESTER | 31247 |
| LUCAS | LRS03814 |
Adapted models
| DACIA | Duster 1.2L H5F404 2013-18 |
| RENAULT | Clio 0.9L H4B400 2012-21 |
| SMART | Fortwo 1.0L M281920 2014-- |
Components
Mounting type
| Mount Hole Dia | 8mm, 3*M10 |
| Flange Dia | N/A |
| Mount Holes Cnt to Cnt | 29mm |
| Pinion Dia | 154mm |
| Out of Mesh Clearance | 19.5mm |
| Overall Length | 193mm |
| HSG Length | 118mm |
| Rest Position B | 139mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.3Kg |
