Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 12T |
| Rotation | CW |
OE NO
| VALEO | TS12E38 |
Ref No
| FORD | AV6N-11000-DA |
| VOLVO | 30659805 |
| LESTER | 30448 |
| LUCAS | LRS02544 |
Adapted models
| FORD | Focus 1.6L (BK) JQDA2010-14 |
| FORD | Kuga 1.6L (DM2)JQMA 2013-14 |
| VOLVO | S60 1.6L B4164T3 2010-16 |
| VOLVO | V40 1.6L B4164T3 2010-15 |
Components
Mounting type
| Mount Hole Dia | M10, M10, M10 |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 105*82.5*67.5mm |
| Pinion Dia | 32mm |
| Out of Mesh Clearance | 27.5mm |
| Overall Length | 201mm |
| HSG Length | 140mm |
| Rest Position B | 117mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG | 2.7Kg |
