Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| VALEO | TS12E36 |
Ref No
| BMW | 12417616500 |
| LESTER | 30304 |
| LUCAS | LRS02495 |
Adapted models
| BMW | 135 3.0L (E82) N55B30A 2011-13 |
| BMW | 335 3.0L (E93) N54B30A 2006-13 |
| BMW | X6 3.0L (E71) N54B30A 2008-14 |
Components
Mounting type
| Mount Hole Dia | 11mm, M10 |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 104.5mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 25.3mm |
| Overall Length | 203mm |
| HSG Length | 141mm |
| Rest Position B | 131mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 2.7Kg |
