Specification
| Volt | 12V |
| Power | 0.9KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| VALEO | D7E19 |
Ref No
| RENAULT | 8200049826 |
| LESTER | 32566 |
| LUCAS | LRS01566 |
Adapted models
| NISSAN | Kubistar 1.6L (X76)K4M752 2003-09 |
| RENAULT | Kangoo 1.6L K4M708 2001-09 |
| RENAULT | Megane 1.6L K4M760 2003-11 |
Components
Mounting type
| Mount Hole Dia | M10, M10, M10 |
| Flange Dia | 64mm |
| Mount Holes Cnt to Cnt | 104.5*67*73mm |
| Pinion Dia | 23.5mm |
| Out of Mesh Clearance | -2mm |
| Overall Length | 167mm |
| HSG Length | 138mm |
| Rest Position B | 134.5mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.0Kg |
