Specification
| Volt | 12V |
| Power | 3.0KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| Denso | 428000-4620 |
Ref No
| TOYOTA | 28100-78150 |
| Denso | 428000-4623 |
| LESTER | 30818 |
Adapted models
| TOYOTA Coaster |
Components
Mounting type
| Mount Hole Dia | M14, 15mm |
| Flange Dia | 105mm |
| Mount Holes Cnt to Cnt | 140.5mm |
| Pinion Dia | 40.1mm |
| Out of Mesh Clearance | 31mm |
| Overall Length | 279mm |
| HSG Length | 241mm |
| Rest Position B | 189mm |
| S terminal size | |
| B+ terminal size | M10 |
| WEIGHT KG | 7.3Kg |
