Specification
| Volt | 12V |
| Power | 1.8KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| Denso | 428000-5320 |
Ref No
| FORD | 8W83-11001-BB |
| JAGUAR | C2D27864 |
| LESTER | 19177 |
| LUCAS | LRS04054 |
Adapted models
| JAGUAR XF 5.0L 508PN 2009-15 | |
| JAGUAR XFR 5.0L 508PS 2009-15 | |
| JAGUAR XJ 5.0L V8 508PN 2009- |
Components
Mounting type
| Mount Hole Dia | M10, 10.8mm |
| Flange Dia | 62mm |
| Mount Holes Cnt to Cnt | 142mm |
| Pinion Dia | 35mm |
| Out of Mesh Clearance | 25.3mm |
| Overall Length | 203mm |
| HSG Length | 141.5mm |
| Rest Position B | 135.5mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
