Specification
| Volt | 24V |
| Power | 4.5KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| NIKKO | 023000-2542 |
Ref No
| ISUZU | 8970298630 |
| LESTER | 18194 |
Adapted models
| ISUZU Engine 4BD1T 1990- | |
| NEW HOLLAND E130 2006- | |
| JOHN DEERE Excavators 135C RTS Isuzu 4BG1TC |
Components
Mounting type
| Mount Hole Dia | 13.5mm, 13.5mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 120mm |
| Pinion Dia | 35mm |
| Out of Mesh Clearance | 18.8mm |
| Overall Length | 331mm |
| HSG Length | 267mm |
| Rest Position B | 233mm |
| S terminal size | |
| B+ terminal size | M10 |
| WEIGHT KG |
