Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| Denso | 428000-0250 |
Ref No
| TOYOTA | 28100-30040 |
| LESTER | 32415 |
| LUCAS | LRS01497 |
Adapted models
| TOYOTA 4 Runner 3.0D 1KZTE 1993-96 | |
| TOYOTA Dyna 100 2.5 D-4D 2KDFTV 2001-06 | |
| TOYOTA Hilux 2.5 D-4D 2KDFTV 2005-16 |
Components
Mounting type
| Mount Hole Dia | 13.5mm,M12 |
| Flange Dia | 82.5mm |
| Mount Holes Cnt to Cnt | 130mm |
| Pinion Dia | 38mm |
| Out of Mesh Clearance | 18.5mm |
| Overall Length | 220mm |
| HSG Length | 190mm |
| Rest Position B | 135mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
