Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| Denso | 128000-1150 |
Ref No
| JOHN DEERE | AM100807 |
| YANMAR | 119620-77011 |
| LESTER | 17382 |
| LUCAS | LRS01360 |
Adapted models
| JOHN DEERE F932 3TNA72 1988- | |
| YANMAR ENGINES 3T7A-2 1984-- |
Components
Mounting type
| Mount Hole Dia | 13mm, 13mm |
| Flange Dia | 95mm |
| Mount Holes Cnt to Cnt | 120mm |
| Pinion Dia | 34mm |
| Out of Mesh Clearance | 20mm |
| Overall Length | 188mm |
| HSG Length | 130.5mm |
| Rest Position B | 155mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
