Specification
| Volt | 12V |
| Power | 1.6KW |
| Teeth | 13T |
| Rotation | CCW |
OE NO
| Denso | 428000-0700 |
Ref No
| TOYOTA | 28100-0H060 |
| LESTER | 17825 |
| LUCAS | LRS02452 |
Adapted models
| TOYOTA Avensis 2.0L 1AZFSE 2003- 08 | |
| TOYOTA Avensis 2.4L 2AZFSE 2003-08 |
Components
Mounting type
| Mount Hole Dia | 12mm, 12mm |
| Flange Dia | 55mm |
| Mount Holes Cnt to Cnt | 122mm |
| Pinion Dia | 40.5mm |
| Out of Mesh Clearance | 66.5mm |
| Overall Length | 214mm |
| HSG Length | 140mm |
| Rest Position B | 126mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
