Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M0T23171 |
Ref No
| SUZUKI | 31100-78K00 |
| LESTER | 19066 |
| LUCAS | LRS03850 |
Adapted models
| SUZUKI | Kizashi 2.4L J24B 2010- |
| SUZUKI | Grand Vitara 2.4L J24B 2009-15 |
Components
Mounting type
| Mount Hole Dia | M10, 11.5mm |
| Flange Dia | 70mm |
| Mount Holes Cnt to Cnt | 101mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 27mm |
| Overall Length | 182mm |
| HSG Length | 120mm |
| Rest Position B | 115mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
