Specification
| Volt | 12V |
| Power | 2.2KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| MITSUBISHI | M8T75071 |
Ref No
| MITSUBISHI | ME201650 |
| LESTER | 32328 |
| LUCAS | LRS01328 |
Adapted models
| MITSUBISHI | Canter 35 2.8D 4M40-2AT 1998- |
| MITSUBISHI | Pajero 3.2 DI-D 4M41 2000-06 |
Components
Mounting type
| Mount Hole Dia | M10, M10 |
| Flange Dia | 77mm |
| Mount Holes Cnt to Cnt | 114mm |
| Pinion Dia | 32.5mm |
| Out of Mesh Clearance | 9mm |
| Overall Length | 240mm |
| HSG Length | 223mm |
| Rest Position B | 164mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
