Specification
| Volt | 24V |
| Power | 3.2KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| MITSUBISHI | M2T65271 |
Ref No
| MITSUBISHI | 34466-03101 |
| LESTER | 18245 |
| LUCAS | LRS01842 |
Adapted models
| MITSUBISHI | FD20 S4E 1983- |
Components
Mounting type
| Mount Hole Dia | 11.8mm, 11.8mm |
| Flange Dia | 82.2mm |
| Mount Holes Cnt to Cnt | 104.5mm |
| Pinion Dia | 41.5mm |
| Out of Mesh Clearance | 22.3mm |
| Overall Length | 249mm |
| HSG Length | 217.5mm |
| Rest Position B | 185mm |
| S terminal size | M5 |
| B+ terminal size | M8 |
| WEIGHT KG | 5.6Kg |
