Specification
| Volt | 12V |
| Power | 2.0KW |
| Teeth | 13T |
| Rotation | CW |
OE NO
| MITSUBISHI | M8T70471 |
Ref No
| CATERPILLAR | 195-8486 |
| MITSUBISHI | 31A66-00101 |
| LESTER | 18974 |
| LUCAS | LRS02741 |
Adapted models
| JCB | 335HST 1.8D S4L2 2008-- |
| TEREX | HR16 1.8D S4L2 2004- |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 77mm |
| Mount Holes Cnt to Cnt | 117mm |
| Pinion Dia | 41mm |
| Out of Mesh Clearance | 30mm |
| Overall Length | 240mm |
| HSG Length | 199mm |
| Rest Position B | 180mm |
| S terminal size | M4 |
| B+ terminal size | M8 |
| WEIGHT KG |
