Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M0T84381 |
Ref No
| MAZDA | FFSC-18-400 |
| HYSTER | 2314322 |
| YALE | 220102437R |
| LESTER | 18096 |
| LUCAS | LRS00500 |
Adapted models
| HYSTER | S-50XL M4-121G 1985-95 |
| YALE | GE [F2] 1999-09 |
Components
Mounting type
| Mount Hole Dia | 12mm,12mm |
| Flange Dia | 74mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 18.5mm |
| Overall Length | 196mm |
| HSG Length | 140mm |
| Rest Position B | 119mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
