Specification
| Volt | 12V |
| Power | 0.8KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M3T34781 |
Ref No
| SUZUKI | 31100-83020 |
| LESTER | 16966 |
Adapted models
| SUZUKI | Jimny 1.3L G13BB 1998-08 |
| SUZUKI | Vitara 1.6L G16B 1990-98 |
Components
Mounting type
| Mount Hole Dia | 9.5mm, 9.5mm |
| Flange Dia | 66mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 28.3mm |
| Out of Mesh Clearance | 4mm |
| Overall Length | 189mm |
| HSG Length | 146mm |
| Rest Position B | 130mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 4.1Kg |
