Specification
| Volt | 12V |
| Power | 0.9KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M3T41081 |
Ref No
| MITSUBISHI | MD081567 |
| LESTER | 16940 |
| LUCAS | LRS00473 |
Adapted models
| MITSUBISHI | Colt 1.5L 4G15 1984-88 |
| MITSUBISHI | L 200 2.0L 4G63 1996--01 |
| HYUNDAI | Accent 1.3L G4EH 1994-99 |
Components
Mounting type
| Mount Hole Dia | M10,M10 |
| Flange Dia | 77mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 18mm |
| Overall Length | 190mm |
| HSG Length | 136mm |
| Rest Position B | 117mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 4.1Kg |
