Specification
| Volt | 12V |
| Power | 1.4KW |
| Teeth | 8T |
| Rotation | CW |
OE NO
| MITSUBISHI | M0T85881 |
Ref No
| SUZUKI | 31100-65DA0 |
| LESTER | 17783 |
| LUCAS | LRS01341 |
Adapted models
| SUZUKI | Grand Vitara 2.0L J20A 1998-05 |
| SSUZUKI | Vitara 2.0L J20A 1996-00 |
Components
Mounting type
| Mount Hole Dia | M10, M10 |
| Flange Dia | 66mm |
| Mount Holes Cnt to Cnt | 100mm |
| Pinion Dia | 28mm |
| Out of Mesh Clearance | 5mm |
| Overall Length | 201mm |
| HSG Length | 160mm |
| Rest Position B | 134mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
