Specification
| Volt | 12V |
| Power | 1.0KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| DENSO | 128000-5581 |
Ref No
| DENSO | 128000-5580 |
| LESTER | 17420 |
| LUCAS | LRS01483 |
| TOYOTA | 28100-65010 |
Adapted models
| TOYOTA | 4-Runner 3.0L [3VZ-E] 1990-1995 |
Components
Mounting type
| Mount Hole Dia | 11mm,M10 |
| Flange Dia | 55mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 28.7mm |
| Out of Mesh Clearance | 16.5mm |
| Overall Length | 180mm |
| HSG Length | 152mm |
| Rest Position B | 136mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.4Kg |
