Specification
| Volt | 12V |
| Power | 2.0KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| DENSO | 428000-0981 |
Ref No
| DENSO | 428000-0980 |
| CHRYSLER | 5037199AA |
| LESTER | 19028 |
| LUCAS | LRS04067 |
Adapted models
| DODGE | VIPER 8.3L [EWC] ZB 2003-06 |
Components
Mounting type
| Mount Hole Dia | 11.4mm |
| Flange Dia | 74mm |
| Mount Holes Cnt to Cnt | 115mm |
| Pinion Dia | 33mm |
| Out of Mesh Clearance | 19.1mm |
| Overall Length | 220mm |
| HSG Length | 188mm |
| Rest Position B | 135mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 4.5Kg |
