Specification
| Volt | 12V |
| Power | 1.5KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| DENSO | 428000-7400 |
Ref No
| CHRYSLER | 4801694AC |
| LESTER | 19203 |
| LUCAS | LRS04216 |
Adapted models
| JEEP | Grand Cherokee 3.6L V6 4x4 [ERB] 2010- |
Components
Mounting type
| Mount Hole Dia | M10,M10 |
| Flange Dia | 68mm |
| Mount Holes Cnt to Cnt | 82mm |
| Pinion Dia | 30mm |
| Out of Mesh Clearance | 33mm |
| Overall Length | 199mm |
| HSG Length | 130mm |
| Rest Position B | 119mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 2.75Kg |
