Specification
| Volt | 24V |
| Power | 4.0KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| BOSCH | 0001231019 |
Ref No
| MAN | 51262017183 |
| LESTER | 31248 |
| LUCAS | LRS01970 |
Adapted models
| MAN | 18.224 6.9D [D0826LFL10] 1995- |
| MAN | NM 152 4.4D [D0824LOH01] 1992-1997 |
Components
Mounting type
| Mount Hole Dia | 11mm,11mm,11mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 81.5*93.5mm |
| Pinion Dia | 40mm |
| Out of Mesh Clearance | 27.5mm |
| Overall Length | 313mm |
| HSG Length | 240mm |
| Rest Position B | 194mm |
| S terminal size | |
| B+ terminal size | M10 |
| WEIGHT KG | 8Kg |
