Specification
| Volt | 12V |
| Power | 1.2KW |
| Teeth | 12T |
| Rotation | CW |
OE NO
| BOSCH | 0001136003 |
Ref No
| BOSCH | 0001136002 |
| RENAULT | 23300-6124R |
| Lester | 30425 |
| LUCAS | LRS02735 |
Adapted models
| MERCEDES BENZ | Citan 108 1.5 CDi (415)[OM607.951] 2013- |
| NISSAN | Pulsar 1.5 dCi [K9K..] 2014- |
| RENAULT | Clio 1.5 dCi [K9K618] 2013- |
| RENAULT | Kangoo 1.5 dCi [K9K608] 01.2013- |
Components
Mounting type
| Mount Hole Dia | M8,M10,M10 |
| Flange Dia | 64mm |
| Mount Holes Cnt to Cnt | 114.5mm |
| Pinion Dia | 31.8mm |
| Out of Mesh Clearance | 0.5mm |
| Overall Length | 213mm |
| HSG Length | 179mm |
| Rest Position B | 151mm |
| S terminal size | M5 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.15Kg |
