Specification
| Volt | 12V |
| Power | 0.8KW |
| Teeth | 9T |
| Rotation | CCW |
OE NO
| BOSCH | 0001212005 |
Ref No
| PORSCHE | 90160410203 |
| VW | 003911023A |
| Lester | 16300 |
| LUCAS | LRS00287 |
Adapted models
| PORSCHE | 911 2.4 Turbo 1971-1973 |
| VW | Transporter 1.8L 1973-1975 |
Components
Mounting type
| Mount Hole Dia | 10.3mm, 10.3mm |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 104.5mm |
| Pinion Dia | 25mm |
| Out of Mesh Clearance | 32.1mm |
| Overall Length | 252.5mm |
| HSG Length | 218mm |
| Rest Position B | 190mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 5.Kg |
