Specification
| Volt | 24V |
| Power | 5.5KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| BOSCH | 0001416053 |
Ref No
| VOLVO | 847330 |
| Lester | 18222 |
| LUCAS | LRS01855 |
Adapted models
| VOLVO PENTA | MD120A 1970-1980 |
| VOLVO PENTA | TMD100 1965-1985 |
Components
Mounting type
| Mount Hole Dia | 11mm,11mm,11mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 90*9*127mm |
| Pinion Dia | 40.5mm |
| Out of Mesh Clearance | 46.8mm |
| Overall Length | 383mm |
| HSG Length | 323mm |
| Rest Position B | 149mm |
| S terminal size | M6 |
| B+ terminal size | M10 |
| WEIGHT KG | 16.2Kg |
