Specification
| Volt | 12V |
| Power | 2.5KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| BOSCH | 0001139021 |
Ref No
| BOSCH | 0001139022 |
| PORSCHE | 94860421400 |
| Lester | 19216 |
| LUCAS | LRS03975 |
Adapted models
| PORSCHE | Macan 3.6 Turbo [MCT.LA] 2014-2018 |
| PORSCHE | Cayenne 3.6 S [MCU.RA] 2014- |
| PORSCHE | Cayenne 4.8 Turbo [M48.52] 2010- |
Components
Mounting type
| Mount Hole Dia | 10.5mm, 10.5mm |
| Flange Dia | 68mm |
| Mount Holes Cnt to Cnt | 103mm |
| Pinion Dia | 27.5mm |
| Out of Mesh Clearance | 29mm |
| Overall Length | 250mm |
| HSG Length | 187mm |
| Rest Position B | 152mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.9Kg |
