Specification
| Volt | 12V |
| Power | 1.7KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| BOSCH | 0001138062 |
Ref No
| BMW | 12417638192 |
| Lester | 30584 |
| LUCAS | LRS03904 |
Adapted models
| BMW | 316 1.6 i (F30)[N13B16A] 2012- |
| BMW | 120 1.6 i (F21)[N13B16A] 2015- |
Components
Mounting type
| Mount Hole Dia | 9mm,9.5mm,M8 |
| Flange Dia | 60mm |
| Mount Holes Cnt to Cnt | 91.5*74*124mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 13.8mm |
| Overall Length | 226mm |
| HSG Length | 178mm |
| Rest Position B | 152mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
