Specification
| Volt | 12V |
| Power | 1.7KW |
| Teeth | 15T |
| Rotation | CW |
OE NO
| DENSO | 428000-9140 |
Ref No
| MERCEDES BENZ | A6459060800 |
| NISSAN | 23300-5DA0B |
| Lester | 16098 |
| LUCAS | LRS03960 |
Adapted models
| MERCEDES BENZ | B 200 1.6L [M270.910] 2015- |
| MERCEDES BENZ | CLA 180 1.5 CDi [OM607.951] 2013- |
| INFINITI | QX30 2.0L 2017-19 |
Components
Mounting type
| Mount Hole Dia | 12mm,12mm |
| Flange Dia | 74mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 38mm |
| Out of Mesh Clearance | 53.5mm |
| Overall Length | 231mm |
| HSG Length | 146mm |
| Rest Position B | 139mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
