Specification
| Volt | 12V |
| Power | 1.7KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001138057 |
Ref No
| BOSCH | 0001138058 |
| BMW | 12417638194 |
| Lester | 33329 |
| LUCAS | LRS02325 |
Adapted models
| BMW | 335 3.0 i (F30)[N55B30A] 2011- |
| BMW | 428 2.0 i (F33)[N20.N26B20A] 2013- |
Components
Mounting type
| Mount Hole Dia | 11mm,M10 |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 25mm |
| Overall Length | 226mm |
| HSG Length | 166mm |
| Rest Position B | 140mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG | 3.3Kg |
