Specification
| Volt | 12V |
| Power | 1.7KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001109029 |
Ref No
| JOHN DEERE | FGL5840089 |
| LOMBARDINI | 58400890 |
| HATZ | 50316401 |
| Lester | 18369 |
| LUCAS | LRS01276 |
Adapted models
| HATZ 2G30 Industrial Engine 1987- | |
| LOMBARDINI Engine [6LD..] 1982-1992 |
Components
Mounting type
| Mount Hole Dia | 11mm,11mm |
| Flange Dia | 76mm |
| Mount Holes Cnt to Cnt | 105mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 27.5mm |
| Overall Length | 238mm |
| HSG Length | 174.5mm |
| Rest Position B | 128mm |
| S terminal size | |
| B+ terminal size | M8 |
| WEIGHT KG |
