Specification
| Volt | 24V |
| Power | 5.5KW |
| Teeth | 11T |
| Rotation | CW |
OE NO
| BOSCH | 0001241008 |
Ref No
| WEICHAI | 612600090293 |
| Lester | 30153 |
Adapted models
| HOWO WD615 | |
| WEICHAI WD615 |
Components
Mounting type
| Mount Hole Dia | 11.2mm,11.2mm,11.2mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 127*89.5*89.5mm |
| Pinion Dia | 49mm |
| Out of Mesh Clearance | 48.3mm |
| Overall Length | 320mm |
| HSG Length | 265mm |
| Rest Position B | 246mm |
| S terminal size | M6 |
| B+ terminal size | M10 |
| WEIGHT KG | 9.4Kg |
