Specification
| Volt | 24V |
| Power | 4.0KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001231005 |
Ref No
| KHD | 1180999 |
| Lester | 18958 |
| LUCAS | LRS01936 |
Adapted models
| IVECO MK 130-16 A 6.1D [BF6L913] 1983-1991 | |
| KHD ENGINES Various Models 2000- |
Components
Mounting type
| Mount Hole Dia | 11mm,11mm,11mm |
| Flange Dia | 89mm |
| Mount Holes Cnt to Cnt | 90*90*127mm |
| Pinion Dia | 34mm |
| Out of Mesh Clearance | 28mm |
| Overall Length | 313mm |
| HSG Length | 239mm |
| Rest Position B | 189mm |
| S terminal size | M4 |
| B+ terminal size | M10 |
| WEIGHT KG |
