Specification
| Volt | 12V |
| Power | 1.1KW |
| Teeth | 10T |
| Rotation | CW |
OE NO
| BOSCH | 0001107417 |
Ref No
| BOSCH | 0001107043 |
| FORD | 2S6U-11000-CA |
| VOLVO | 30667102 |
| Lester | 31167 |
| LUCAS | LRS02716 |
Adapted models
| FORD | Fiesta 1.4L [RTJA] 2008-2012 |
| FORD | Focus 1.6L [SHDB] 2006-2010 |
| VOLVO | V50 1.6L [B4164S3] 2005-2012 |
Components
Mounting type
| Mount Hole Dia | M10, M10, M10 |
| Flange Dia | 76.1mm |
| Mount Holes Cnt to Cnt | 67.5*82.5*105mm |
| Pinion Dia | 26.3mm |
| Out of Mesh Clearance | 27mm |
| Overall Length | 218.5mm |
| HSG Length | 151mm |
| Rest Position B | 136mm |
| S terminal size | M6 |
| B+ terminal size | M8 |
| WEIGHT KG |
