Specification
| Volt | 12V |
| Power | 2.3KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001223016 |
Ref No
| BOBCAT | 6688189 |
| DEUTZ | 1181751 |
| KHD | 1182384 |
| Lester | 18951 |
| LUCAS | LRS01755 |
Adapted models
| KHD Engine 3.0 [BF4M2011] 2000- | |
| KHD Engine 3.2 [BF4L2011] 2002- | |
| VOLVO L20B 3.7 [D3.6D] 2002-2009 |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 82.5mm |
| Mount Holes Cnt to Cnt | 101.5mm |
| Pinion Dia | 34mm |
| Out of Mesh Clearance | 23.5mm |
| Overall Length | 255mm |
| HSG Length | 190mm |
| Rest Position B | 152mm |
| S terminal size | M4 |
| B+ terminal size | M8 |
| WEIGHT KG |
