Specification
| Volt | 12V |
| Power | 2.0KW |
| Teeth | 9T |
| Rotation | CW |
OE NO
| BOSCH | 0001109035 |
Ref No
| JCB | 714-35600 |
| PERKINS | 1850866 |
| Lester | 18949 |
| LUCAS | LRS01580 |
Adapted models
| JCB | Midi CX 2.2 [404C-22] 2006-2015 |
| PERKINS Engine 2.2D [134ci] 2002-2012 | |
| PERKINS Engine 1.1 [403C-11G] 2004-2014 |
Components
Mounting type
| Mount Hole Dia | 11mm, 11mm |
| Flange Dia | 74mm |
| Mount Holes Cnt to Cnt | 110mm |
| Pinion Dia | 29mm |
| Out of Mesh Clearance | 19.5mm |
| Overall Length | 238mm |
| HSG Length | 183mm |
| Rest Position B | 136mm |
| S terminal size | M8 |
| B+ terminal size | M8 |
| WEIGHT KG | 3.8Kg |
